CODIGO
#include <LiquidCrystal_I2C.h> // Debe descargar la Libreria que controla el I2C #include<Wire.h> LiquidCrystal_I2C lcd(0x27, 20, 4); const int pulsador_ = 3; const int bomba = 12; volatile double waterFlow; boolean state = false; int pulsador; void setup() { lcd.init(); lcd.backlight(); lcd.setCursor(1, 0); lcd.print("ELECTROALL."); delay(600); lcd.clear(); lcd.setCursor(0, 0); lcd.print("waterFlow: "); lcd.print(waterFlow); lcd.print(" L"); waterFlow = 0; pinMode(pulsador_, INPUT_PULLUP); //Resistencia de pullup interna attachInterrupt(0, pulse, RISING); //DIGITAL Pin 2: Interrupt 0 pinMode(bomba, OUTPUT); } void loop() { pulsador = digitalRead(pulsador_); if (pulsador == 0) { digitalWrite(bomba, 1); state = true; waterFlow = 0; } if (state == true) { lcd.setCursor(0, 0); lcd.print("waterFlow:"); lcd.print(waterFlow); lcd.print("L"); } if (waterFlow >= 1) { digitalWrite(bomba, 0); state = false; } } void pulse() //measure the quantity of square wave { waterFlow += 1.0 / 450.0; }
